Genset Generator Auto Controller Dse 4520MK2 DSE 4520 MKII DSE4520 Intelligent Generator Controller
4520MK2
minimum order
1 carton
Quantity
$100.00 - $150.00 / carton
- Place of Origin:Fujian, China
- Brand Name:no
- Model Number:4520MK2
- rated current:1A
- Product Name:Generator Controller
- Packing:Carton
- Color:Black
- Quality Class:High Quatity
- Stock:4520MK2
- Usage:Distant Control,Multi-Protection, LED data display
- Function:Intelligent Automatic Generator controller
- Warranty:1 year warranty
- WEIGHT:1kg
Genset Generator Auto Controller Dse 4520MK2 DSE 4520 MKII DSE4520 Intelligent Generator Controller
Description
Reliable and extremely performance.
Each control has been tested, and the each buttons undergoes fifty thousand test. Same quality as the original.Ensure that each product is used by customers assured.
Main function
Emergency parking control
Start motor automatic detection
Preheating
Emergency parking control
Start motor automatic detection
Preheating
DC SUPPLY | CONTINUOUS VOLTAGE RATING | 8 V to 35 V Continuous |
MAXIMUM OPERATING CURRENT | 340 mA at 12 V, 160 mA at 24 V | |
MAXIMUM STANDBY CURRENT | 160 mA at 12 V, 80 mA at 24 V | |
CHARGE FAIL/EXCITATION RANGE | 0 V to 35 V | |
MAINS (UTILITY) | VOLTAGE RANGE | 15 V to 415 V AC (Ph to N) |
26 V to 719 V AC (Ph to Ph) | ||
FREQUENCY RANGE | 3.5 Hz to 75 Hz | |
OUTPUTS | OUTPUT A (FUEL) | 15 A DC at supply voltage |
OUTPUT B (START) | 15 A DC at supply voltage | |
OUTPUTS C & D | 8 A 250 V (Volt free) | |
AUXILIARY OUTPUTS E,F,G,H | 2 A DC at supply voltage | |
GENERATOR | VOLTAGE RANGE | 15 V to 415 V AC (Ph to N) |
26 V to 719 V AC (Ph to Ph) | ||
FREQUENCY RANGE | 3.5 Hz to 75 Hz | |
MAGNETIC PICK-UP | VOLTAGE RANGE | +/- 0.5 V to 70 V |
FREQUENCY RANGE | 10,000 Hz (max) |
How to choose a suitable Generator Controller | ||||||||||||
Cheap(for low cost small power generators) | ||||||||||||
DSE3110 | DSE4520 | DSE4620 | DSE501K | DSE701 | DSE702 | DSE704 | ||||||
More Functions(for high power generator) | ||||||||||||
DSE5110 | DSE5220 | DSE6020 | DSE6120 | DSE7210 | DSE7310 | DSE7320 | ||||||
More languages | ||||||||||||
Avaliable languages:Englines,Spanish,Portuguese,French,German,Russian,Thai,Arabic,Chinese etc | ||||||||||||
DSE6120 | DSE7210 | DSE7220 | DSE7310 | DSE7320 | ||||||||
AMT Generator Controller(Auto Mains Fsilure Generator control Modules) | ||||||||||||
DSE704 | DSE720 | DSE5220 | DSE6120 | DSE7220 | DSE7320 | |||||||
Synchronising and Load Share DSE Controller | ||||||||||||
DSE8610 | DSE8620 | DSE8660 | ||||||||||
Canbus ECU Communications Generator Controller | ||||||||||||
DSE3110 | DSE4520 | DSE7210 | DSE7220 | DSE7310 | DSE7320 | |||||||
parameter
Controll Funtion | Protection Funtion | Data display |
Emergency Stop | Low-Lub oil pressure | Speed |
Manual Start/stop | Charge Failure | Voltage of battery |
Distance Start/Stop | Emergency STOP | Lub oil pressure |
Preheat Control | High speed start/shop failure | Operation time |
Stop/idle control | High Speed/Start and stop failure | Voltage/Current |
Our Services
Guangling strictly adopt the international warranty.
Warranty: Guarantee for one year or 1000 running hours (accord to whichever reach first) from shipment date.
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
FAQ
Q1: What is your MOQ of this item?
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
