Brush AVR GB130 Automatic Voltage Compound Excitation Generator Control Board Stabilizer GB-130
GB-130
minimum order
1 carton
Quantity
$30.00 - $50.00 / carton
- Application:Alternator
- Place of Origin:Fujian, China
- Brand Name:NO
- Model Number:GB-130
- rated current:80A
- Type:Actuator, Rectifier Diode, Auto Start, Automatic Voltage Regulator AVR R250 for Diesel Generator
- Material:iron
- generator type:diesel generator
- Product Name:avr
- package:carton packing
- MOQ:1
- AC Single/Three Phase:Can be supplied
- Alternator:Stamford / Leory Somer / China, etc
- Rated Voltage:110V / 240V, 220V / 380V, 230V / 400V, 240V / 415V
- Gross/Net Weight:0.35kg
- Keyword:GB-130
- Warranty:3months-1year
Product Overview
Brush AVR Automatic Voltage Compound Excitation Generator Control Board Stabilizer GB-130
PRODUCT SPECIFICATIONS
Product Name | Automatic Voltage Regulator AVR R150 for Generators |
Model | GB-130 |
SENSING/POWER INPUT Voltage | 240 VAC ± 10% for 1-phase, 380 V to 480 VAC ± 10% for 3-phase, 2-line sensing |
MAGNETIC FIELD OUTPUT Voltage | 105 VDC at 240 VAC input |
MAGNETIC FIELD OUTPUT Current | 6 A DC • 8 A for 30 sec. (when allowed by the field resistance) |
Voltage setting | min ± 10% of rated voltage. |
Input power | Voltage: 415 V for 3-phase and 240 V for 1-phase |
Frequency: 50/60 Hz | |
Output power | Voltage: 105 VDC at 240 VAC input |
Current:6 A DC | |
8 A for 30 sec. (when allowed by the field resistance) | |
Operating temperature | -20ºC to +70ºC |
Storage temperature | -40ºC to +80ºC |
Our Services
Guangling strictly adopt the international warranty.
Warranty: Guarantee for one year or 1000 running hours (accord to whichever reach first) from shipment date.
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
FAQ
Q1: What is your MOQ of this item?
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
